Toll HIP
AIP offers toll HIP, WIP, and CIP to customers as an economical way to explore the process and determine the benefits derived from its use. AIP staff has a broad background in many materials and methods used for consolidation of powder metals, ceramics, and composites. AIP uses NIST traceable thermocouples and pressure transducers to assure accurate data is being derived. A chart of every cycle is logged and supplied to the customer for analysis. AIP can typically turn cycles around in 5 days. Rush delivery can be arranged if required. AIP treats all cycles as proprietary and protects each client’s interest.
| AIP Toll HIP Systems | ||||||
| System | Diameter | Length | Pressure | Kanthal | Molybdenum | Carbon |
| AIP6-45H | 70mm | 125mm | 310 MPa | 1200 C | 1400 C | 2200 C |
| AIP6-60H | 100mm | 150mm | 414 MPa | 1400 C | ||
| AIP6-60H | 70mm | 125mm | 414 MPa | 1200 C | 2200 C | |
| AIP14-30H | 225mm | 500mm | 207 Mpa | 1350 C | 2100 C | |
| AIP22-15H | 400mm | 1800mm | 103 MPa | 1250 C | ||
| AIP24-30H | 430mm | 2150mm | 207 MPa | 1225 C | ||
| AIP29-15H | 580mm | 1500mm | 103 MPa | 1200 C | ||
| AIP29-15H | 500mm | 1200mm | 103 MPa | 1900 C | ||
* Oxygen HIP is available with up to 20% Oxygen for oxide ceramics
** Nitrogen HIP is available with 100 % Nitrogen for nitride ceramics (carbon furnace only)
AIP also offers Toll SinterHIP, WIP & CIP – Contact AIP for current capabilities and pricing.
