Superior HIP Technology
HOT ISOSTATIC PRESSES
A Leader in HIP Innovation & Dependability
For more than 30 years American Isostatic Presses has led the industry in developing cutting edge hot isostatic pressing (HIP) technology. AIP has never had a failure of any pressure system we’ve installed. Our customers in industries like aerospace, defense, medical, and manufacturing rely on our engineering expertise for reliable HIP systems that stand the test of time and perform well under intense pressure.
Benefits of Hot Isostatic Pressing
HIP technology is a component-forming process used to uniformly densify containerized shapes in metal, ceramic, and plastic at high temperatures. With typical pressures from 1,035 to 2,070 bar (15,000 to 30,000 psi) and temperatures up to 2,000°C (4,000°F), HIP can achieve 100% of maximum theoretical density for high-performance applications,improving the ductility and fatigue resistance of critical materials. Common applications for HIP include defect healing of castings, consolidation of powder metal and ceramic parts or diffusion bonding.
No AIP pressure system has ever failed
Achieve 100% of theoretical density
Reduce energy consumption up to 50%
Experience the highest cost-efficiency
Decrease scrap loss and reduce mechanical scatter
Stress relief of MIM and AM parts
Speak with a Specialist
Contact our team to get answers from highly trained industry professionals!
AIP6-30H
OUR MOST POPULAR HIP MODEL
The AIP6-30H continues to be the system of choice for small research applications. With a low cost and long life it offers the capability to run fast cycles from vacuum to full pressure, including SinterHIP capabilities. Many furnace options exist and systems are available with glove box operation.
AIP10-30H
A LEADING HIP PRODUCT FROM OUR LINE
When you need more than research but aren’t ready for production there is only one choice. That is the AIP10-30H. This HIP system has a 150mm diameter x 300mm long hot zone that is perfect for scaling up samples. As with all AIP systems this unit is super reliable and simple to operate.
AIP18-30H
A LEADING HIP PRODUCT FROM OUR LINE
The AIP18-30H is for small scale production and can be located above ground or in a pit depending on roof height. With a hot zone of 300mm diameter it is available in 3 different lengths including 400, 700, and 900mm versions.
AIP24-30H
A LEADING HIP PRODUCT FROM OUR LINE
The AIP24-30H features a 400mm diameter x 1500mm long hot zone..
AIP52-15H
A LEADING HIP PRODUCT FROM OUR LINE
AIP52-15H hot isostatic press. This large production sized system features an 1100mm dia. x 2500mm long hot zone at 103MPa.
How Does HIP Work?
During Hot Isostatic Pressing, pressure is applied to a material uniformly from all directions through an inert gas (usually Argon) in a pressurized vessel. Heat is applied to the containment chamber throughout the process to increase this pressure over time. The inert gas ensures that no chemical reaction occurs with the material during the process. The application of both heat and pressure simultaneously on all surfaces of a material helps to eliminate any small gaps (pores) in the material thus increasing density and uniform composition.
Why choose Hot Isostatic Pressing?
HIP allows us to squeeze the porous impurities out of materials in order to improve a number of material characteristics. In sintering (powder metallurgy), for example, the process compresses the volume of metal powder at such high pressures and temperatures, that through a combination of deformation, creep, and diffusion bonding you actually create a completely homogenous annealed microstructure with minimal or no impurities in the material. This improves the product’s density, static strength, tensile strength, and abrasion resistance
Speak with a Specialist
Contact our team to get answers from highly trained industry professionals!
Why American Isostatic Presses?
Expertise
Over 30 years of knowledge and experience guides our work.
Integrity
Privately held with longstanding client relationships in all sectors.
Quality
Award-winning and board certified craftsmanship you can trust.
Our Superior Press Technology is Worldwide
Aerospace
Advanced isostatic presses ensure aerospace components meet rigorous standards of strength and precision.
Energy
Efficient, high-quality component manufacturing for the energy industry is supported by specialized presses.
Medical
Isostatic presses enhance the development of medical devices, ensuring durability and precision.
Defense
Robust isostatic presses are essential for producing high-standard, reliable components for defense.
Automotive
Automotive manufacturing benefits from presses that enhance component durability and accuracy.
Space
Specialized presses support space exploration by providing components that withstand extreme conditions.
